Showing 145–168 of 290 results
-
wideband FM antenna with a maximum capacity of 5KW and a 7/8 ″ connector is made entirely of aluminum-treated allodyne and is especially recommended for high-power transmitters. They are very strong but light, with PTFE insulation and stainless steel clamps and screws. They are removable in several parts to facilitate shipping.
All metal parts are grounded to avoid potential lightning problems. For proper operation, they should be mounted on a support pole not too large and, if possible, without other antennas or metal structures nearby. This antenna is particularly suitable for urban installations where multiple reflections multipath are a problem and circular polarization dramatically reduces negative effects.
-
5kW FM Power Divider Standard models are 2-way, 4-way, 6-way, and 8-way dividers. Others available on request. Simple to install, these power dividers come complete with matching mounting clamps and are ideal for feeding an array of antennas to allow you to increase your coverage area without having to upgrade your transmitter power. FM power…
-
CIRCULARLY POLARIZED FM DIPOLE ANTENNA These antennas have been designed to obtain circularly polarized radiant patterns, for low and medium output power FM radio transmitters. For easy and low cost transportation, the models are disassembled and duly packed. The EPC5 model is factory tuned onto any channels in the band 87.5-108 MHz according to customer’s…
-
Relay System FM Repeater FM Booster FM Transposer FM Rebroadcast
-
FM Receiver & Re-broadcast The FM receiver / Re-broadcast from ELETEC BROADCAST offers state-of-the-art performance for FM reception quality. Transport high quality stereo audio signals from the studio to the broadcast sites. Large selection of frequencies and power. Long distance coverage. Technical data: FREQUENCY RANGE 87.5 ÷ 108MHz CHANNEL ADJUSTMENT By means of…
-
LOG 1.5 GHz radio link directive antenna LOG/1.5G – Technical parameters Frequency range 1100-1700 MHz Polarization Horizontal or Vertical Connector N female Maximum power handling capability 300 W Gain (at mid band, ref. to λ/2 dipole) 11.5 dBd Impedance 50 ohm Front to back ratio > 20 dB Wind load (ref. 150 Km/h) 11 Kg…
-
LOG 5 radio link directive antenna 470-860 MHz, broadband gain 10.5 dB. Logarithmic. Aluminium, N connector. Max.
-
LOG FM radio link directive antenna 87.5-108 MHz, broadband, gain 7.5 dB. Logarithmic. Aluminium, N connector. Max. power 100 W
-
LOG/2.5 GHz radio link directive antenna 1.8-2.5 GHz, gain 12.8 dB, broadband.
-
Microwave Radio Link 1100-2700 MHz Microwave Radio Link TL1515 operate on the band range 1.100 – 2.700 GHz Transmitter Frequency Range: 1100~2700 MHz -20MHz sub-band Type of Modulation FM Class F3 VCO Tuning 25 MHz Frequency Stability ± 2,5ppm (Bettr 0n request) Synthesizer Step 25KHz Power Output 1 or 5 Watts Spurious Emission < -80…
-
Package 8 Bay Dipole FM Antenna and Accessories – Wide Band Max Power: 15kW Complete Package composed by: 8 Bay Dipole FM Antenna – Wide Band – Stainless, 50 meters of 7/8 inch Coaxial Cable with connectors, grounding kit, Connector – Max Power: 15kW – Gain: 11dBd
-
-
RADIO LINK LOG ANTENNA 230÷470MHz Frequency: 230 ÷ 470MHz Impedance: 50 ohms VSWR: <1.7 Gain: 8dBi Front to back ratio: > 20dB Polarisation: Vertical or Horizontal Shock Protection: All parts direct earth grounded RF Power: 30W Connector: NF Material: Aluminium Number of elements: 10 all removable Length: 1050mm Width: 660 mm Weight: 1,2 Kg…
-
STL Radio Link Receivers Audio Equipment
Links Study to Transmitter. An easy solution for connecting terrestrial audio.
Wide selection of frequencies and distances.
Great audio quality.
-
STL Radio Link Transmitters Aural Equipment
Links Study to Transmitter.
An easy solution for connecting terrestrial audio.
Wide selection of frequencies and distances.
Great audio quality.
• Extended Frequency Range
• Nominal RF power 5W-10W-20W
• High stereo performance typ. 50 dB
• Extremely low distortion 0,1%
• Ac mains 90-260 VAC extend range with PFC
• Available frequencies from 200 MHz to 2.5 GHz
-
Available in various ranges: 150-470 Mhz, 830-960 Mhz
Easy setting frequency on two pre-programmed channels User programming of two headphone monitoring outputs
-
STL Amplifier 1.5 – 2.5 Ghz, 40 W 1525HP 40 W output Power
-
STL Antenna 1200-1700MHz A high performance antennafor use with STL links in the 1200Mhz – 1521 Mhz range Designed for STL systems in the 1200-1700 MHz range this Yagi directional antenna has 12 dBi gain and is made from sturdy aluminum for long term performance & reliability. All metal parts are DC grounded for…
-
STL Link Antenna STL LINK VHF – UHF – SHF STL CORNER REFLECTOR VHF – UHF ANTENNAS, STAINLESS STEEL These STL Corner Antennas for VHF-UHF have High Gain, are completely demountable but strong because made in Stainless Steel. FREQ. BAND (Mhz) 200 – 250 300 – 360 380 – 530 IMPEDANCE (Ohm) 50…
-
STL Studio Transmitter Link Equipment
Frequency Range: 170MHz – 2.5GHz
Transmitters, Receivers and Amplifiers to link the Studio to the Radio Station.
-
STL RADIO LINK UHF Frequency range 200 to 960MHz – Analog Stereo encoder/decoder – Digital input/output card – RF and IF Input Monitor Frequency Range: 200~960 MHz and 1.3-2.5 GHz in 20MHz sub-band Type of Modulation FM Class F3 VCO Tuning 25 MHz Frequency Stability ± 2,5ppm (Bettr 0n request) Synthesizer Step 25KHz Power Output…
-
AM Transmitter Solid State 500 watts AM Transmitter Solid State 500 watts Modulation PDM Power Modules connected PLUG-IN 2 Power Modules of 500 watts. Protections of all its parts with fault signalling. A lightning controller output tank, against lightning. 140% of Modulation Capacity in the positive peek. High efficiency, typically 80% or better. Excellent…
-
TRANSMITTER AM COMPACT 1000w NEW
-
AM Transmitter Solid State 1.500 watts AM Transmitter Solid State 1.500 watts Compact Cabinet Stainless Steel. 100% Solid State MOSFET Tecnology Modulation PDM Modular Architecture Power Modules connected PLUG-IN 3 Modules Power of 1,000 watts each one. Protections of all its parts with fault signalling. A lightning controller output tank, against lightning. 140% of Modulation…
