LOG FM radio link directive antenna
LOG FM radio link directive antenna 87.5-108 MHz, broadband, gain 7.5 dB. Logarithmic. Aluminium, N connector. Max. power 100 W
Affichage de 169–192 sur 323 résultats
-
-
LOG/2.5 GHz radio link directive antenna
LOG/2.5 GHz radio link directive antenna 1.8-2.5 GHz, gain 12.8 dB, broadband.
-
Microwave Radio Link 1100-2700 MHz
Microwave Radio Link 1100-2700 MHz Microwave Radio Link TL1515 operate on the band range 1.100 – 2.700 GHz Transmitter Frequency Range: 1100~2700 MHz -20MHz sub-band Type of Modulation FM Class F3 VCO Tuning 25 MHz Frequency Stability ± 2,5ppm (Bettr 0n request) Synthesizer Step 25KHz Power Output 1 or 5 Watts Spurious Emission < -80…
-
MW Links
MW Links – NEW We offers a wide variety of product covering : Fixed to Mobile Links; Half-Duplex and Full-Duplex; Point-to-Point and Point-to-Multipoint Links, Split Mount, Full-Indoor We offers, also : Full-Outdoor; Hot-Stand-By, Space-Diversity and Frequency-Diversity; COFDM Non-Line of Sight and Satellites Links as well. NEW Solution : providing point-to-point broadcast and data transmission technology…
-
-
Package 8 Bay Dipole FM Antenna and Accessories
Package 8 Bay Dipole FM Antenna and Accessories – Wide Band Max Power: 15kW Complete Package composed by: 8 Bay Dipole FM Antenna – Wide Band – Stainless, 50 meters of 7/8 inch Coaxial Cable with connectors, grounding kit, Connector – Max Power: 15kW – Gain: 11dBd
-
-
RADIO LINK LOG ANTENNA 230÷470MHz
RADIO LINK LOG ANTENNA 230÷470MHz Frequency: 230 ÷ 470MHz Impedance: 50 ohms VSWR: <1.7 Gain: 8dBi Front to back ratio: > 20dB Polarisation: Vertical or Horizontal Shock Protection: All parts direct earth grounded RF Power: 30W Connector: NF Material: Aluminium Number of elements: 10 all removable Length: 1050mm Width: 660 mm Weight: 1,2 Kg…
-
RADIO LINK RECEIVER 1.3-2.5 Ghz
STL Radio Link Receivers Audio Equipment
Links Study to Transmitter. An easy solution for connecting terrestrial audio.
Wide selection of frequencies and distances.
Great audio quality.
-
RADIO LINK TRANSMITTER 1.3-2.5 Ghz 5W
STL Radio Link Transmitters Aural Equipment
Links Study to Transmitter.
An easy solution for connecting terrestrial audio.
Wide selection of frequencies and distances.
Great audio quality.
• Extended Frequency Range
• Nominal RF power 5W-10W-20W
• High stereo performance typ. 50 dB
• Extremely low distortion 0,1%
• Ac mains 90-260 VAC extend range with PFC
• Available frequencies from 200 MHz to 2.5 GHz -
REPORTAGE UNIT ERP-TX
Available in various ranges: 150-470 Mhz, 830-960 Mhz
Easy setting frequency on two pre-programmed channels User programming of two headphone monitoring outputs
-
STL Amplifier 1.5 – 2.5 Ghz 40 W 1525HP
STL Amplifier 1.5 – 2.5 Ghz, 40 W 1525HP 40 W output Power
-
STL Antenna 1200-1700MHz
STL Antenna 1200-1700MHz A high performance antennafor use with STL links in the 1200Mhz – 1521 Mhz range Designed for STL systems in the 1200-1700 MHz range this Yagi directional antenna has 12 dBi gain and is made from sturdy aluminum for long term performance & reliability. All metal parts are DC grounded for…
-
STL Link Antenna
STL Link Antenna STL LINK VHF – UHF – SHF STL CORNER REFLECTOR VHF – UHF ANTENNAS, STAINLESS STEEL These STL Corner Antennas for VHF-UHF have High Gain, are completely demountable but strong because made in Stainless Steel. FREQ. BAND (Mhz) 200 – 250 300 – 360 380 – 530 IMPEDANCE (Ohm) 50…
-
STL Radio Link
STL Studio Transmitter Link Equipment
Frequency Range: 170MHz – 2.5GHz
Transmitters, Receivers and Amplifiers to link the Studio to the Radio Station.
-
STL RADIO LINK UHF
STL RADIO LINK UHF Frequency range 200 to 960MHz – Analog Stereo encoder/decoder – Digital input/output card – RF and IF Input Monitor Frequency Range: 200~960 MHz and 1.3-2.5 GHz in 20MHz sub-band Type of Modulation FM Class F3 VCO Tuning 25 MHz Frequency Stability ± 2,5ppm (Bettr 0n request) Synthesizer Step 25KHz Power Output…
-
AM Transmitter Solid State 500 watts
AM Transmitter Solid State 500 watts AM Transmitter Solid State 500 watts Modulation PDM Power Modules connected PLUG-IN 2 Power Modules of 500 watts. Protections of all its parts with fault signalling. A lightning controller output tank, against lightning. 140% of Modulation Capacity in the positive peek. High efficiency, typically 80% or better. Excellent…
-
-
AM Transmitter Solid State 1.500 watts
AM Transmitter Solid State 1.500 watts AM Transmitter Solid State 1.500 watts Compact Cabinet Stainless Steel. 100% Solid State MOSFET Tecnology Modulation PDM Modular Architecture Power Modules connected PLUG-IN 3 Modules Power of 1,000 watts each one. Protections of all its parts with fault signalling. A lightning controller output tank, against lightning. 140% of Modulation…
-
TV & Digital Radio Audio Processor Falcon X7 – Radio products
TV & Digital Radio Audio Processor Falcon X7 – Radio products
-
-
UHF TV power splitters, band IV-V, freq 470-854MHz
UHF TV power splitters, band IV-V, freq 470-854MHz They are made of aluminum and externally powder painted. PTFE insulator and washers O-Ring on connectors and closure caps.
-
470-860 MHz Transmitting Antennas
ELETEC 4 dipoles antenna with panel reflector and protection radome
-
EUHF UHF Panel antenna 470-860 MHz 1kW 9,5-12 dB
ELETEC 4 dipoles antenna with panel reflector and protection radome
